T2652-S
T2652-S
- The T2652-S 6.50" is an alternative component system to the T1 with a major difference being a Billet aluminum phase plug to enhance cooling. The woofer features the same VAST surround having up to 25% increased cone area and a Flex Fit Basket for easy mounting. Another difference is the Aluminum Dome Neo-Tweeter for Fanatics who prefer this type of tonal quality over the T1. The same external audiophile crossover is used, configurable for single or bi-amp configurations.
PLEASE CALL FOR PRICING.
General Features
- Aluminum dome neo-tweeter with integral suspension
- Internal tweeter mylar phase plug
- Carbon fiber & polypropylene injection molded cone
- Billet machined aluminum phase plug
- FlexFit basket design
- Butyl midrange rubber surround
- Recessed tweeter mount uses standard 1-3/4" hole saw
- 3 levels of tweeter attenuation
- On-axis/off-axis tweeter configuration
- Bi-amp on/off capability
- 5% tolerance high quality poly-capacitors and air-core inductors
- External audiophile grade component crossover
- 1 Year Warranty
- Sold in pairs (2 each)
- OEM adapter plate included
Technologies
CEA-2031
Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.
DDC™ Tweeter Mounting
Our DDC™ (Discreet Dual Clamp) Tweeter Mounting provides concentric clamping pressure around the perimeter of the mounting hole. This results in maximum ease of installation.
Klippel Verified
Klippel is a speaker certification program allowing us to deliver the best possible speakers.
PTC Protection
Allows tweeter protection with a bypass resistor for 100% run-time.
VAST Surround (speakers)
The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.
FlexFit Basket - Speaker
The slot mounted frame pattern allows for variable adjustments to the mounting position.
Multi-OEM Adapter
The Multi-OEM Adapter plate allows round component or full-range speakers to fit in certain OEM openings. This allows the speaker the capacity to fit more vehicles.
The "Axis" function can be used in conjunction with any tweeter level setting, allowing you to target a sonic preference.
Specifications
- CEA-2031 Compliant
- Speaker Type
- Component System
- Tweeter Size (Nominal Diameter)
- 1.0" (25.4 mm)
- Tweeter Mounting Depth
- 0.50" (13 mm)
- Midrange Mounting Depth
- 2.51" (64 mm)
- Midrange Size (Nominal Diameter)
- 6.5"
- Nominal Impedance (Ohms)
- 4-Ohm
- Mounting Hardware
- Yes
- Frequency Response (Hz)
- 55Hz - 22kHz
- Power Handling (RMS)
- 100 Watts RMS
- 200 Watts Max
- Crossover
- High-Pass (HP): 3.0kHz @ 18dB/octave Butterworth
- Low-Pass (LP): 3.0kHz @ 12dB/octave Butterworth
- Grille/Trim Ring Included
- Yes
- Sensitivity (dB @ 1W/1M)
- 89
- Shipping Weight
- 9.4 Lbs. (4.26 kg.)
