MVH-1400NEX
MVH-1400NEX
- 6.2" - Bluetooth®, Apple CarPlay®, SiriusXM-Ready™ and AppRadio Mode + - Multimedia Digital Media Receiver
- Apple CarPlay® Compatible
- Built-in Bluetooth®
- Back-Up Camera Ready
- Spotify®, Works with Pandora®, SiriusXM-Ready™
- Notice: Discontinuance of Waze in AppRadio Mod
What’s in the Box
- Digital media receiver w/ fixed 6.2" touchscreen monitor (10A fuse inserted in chassis)
- Wiring harness
- 58" USB extension cable
- Microphone w/ mounting-bracket (attached 13' cable terminated by a right-angle 2.5mm connector)
- Two-sided tape
- 6 Pan-head ISO screws (M5 x 6mm)
- 6 Flat-head ISO screws (M5 x 6mm)
- Quick Start Guide
- Installation Manual
- Warranty Information
Specifications
STANDARDS
| CTA-2006 | Yes |
PERFORMANCE
| Continuous Power Output | 22 W x 4-Channel |
| Load Impedance Allowance | 4 Ohm (4 Ohm to 8 Ohm Allowable) |
| Max Power Output | 50 W x 4-ch 4 ohm / 50 W x 2-ch 4 ohm + 70 W X 1-ch (subwoofer) 2 Ohm |
| RCA Preamp Outputs | 6-Channel |
| RMS Power Output (CTA-2006) | 14 W RMS x 4-ch 4 ohm |
DISPLAY
| Back Light | LED |
| Brightness Control | Yes |
| Color Customization | 5 display colors, 112 key colors |
| Device (Non-DIN/Modular Unit) | 2-DIN |
| Dimmer | Dimmer Trigger |
| Home Screen Customization | Yes |
| Resolution | WVGA (800 x 480) |
| Screen Size/Aspect Ratio | 6.2"/16:9 |
| Touch Screen | Capacitive |
BLUETOOTH
| Advanced Audio Distribution Profile (A2DP) | Yes |
| AVRCP | 1.6 |
| Built-in Bluetooth® | Yes |
| Hands-Free | Yes |
| Secure Simple Pairing (SSP) | Yes |
| Serial Port Profile (SPP) | Yes |
| Sound Retriever Air | Mode 1/Mode 2/Off |
TUNER
| Best Station Memory | Yes |
| Local Seek tuning | Yes |
| Presets | 18 FM, 6 AM |
| RDS | Yes |
| SiriusXM-Ready™ (Tuner Sold Separately) | Yes |
INTEGRATION
| Apple® CarPlay | Wired USB Connection |
| AppRadio Mode+ | Yes |
| Mobile Operating System | Android / Apple iOS |
| Music Playback (MTP) | Yes |
| Pandora® | Android via Bluetooth, iPhone via Bluetooth |
| Pioneer App Compatibility | AppRadio Live Android, AppRadio Live iPhone |
| Siri® Eyes Free (VR) (Internet Required) | iPhone Only |
DIGITAL MEDIA PLAYBACK
| Audio Playback via USB | MP3 Audio Playback / WMA Audio Playback / AAC Audio Playback / FLAC Audio Playback (Hi-Res) / WAV Audio Playback (Hi-Res) |
| Audio Video Playback via USB | H.263 / H.264 / .avi / .mpg/mpeg / .divx / .mp4 / .3gp / .mkv / .mov / .flv / .wmv/.asf / .m4v |
| Image Display via USB | BMP / JPEG / PNG |
AUDIO
| Auto EQ (CD-MC20 Microphone sold separately) | Yes |
| Built-in Amplifier | MOSFET 50 W x 4 |
| Customizable Graphic Equalizer | 13 Band |
| DA Converter | 24 Bit |
| Easy EQ (EEQ) Preset Equalizer | Yes |
| Listening Position Selector | Variable |
| Loudness | High/Mid/Low/Off |
| MIXTRAX® | Yes |
| Speaker Output | 4-Channel |
| Time Alignment | Manual |
EXPANDABILITY
| OEM Integration | iDatalink® Maestro™ - RR |
| RCA Video Output | Yes |
| USB | Single Rear Type-A (5 V, 1.5 A) |
| USB Direct Control for iPhone® | 5s and newer |
INPUTS
| Input 1 | Backup Camera Dedicated |
| Input 2 | AUX (Minijack) |
| Input 3 | AV |
GENERAL
| Detachable Face Security | Fixed |
| Multi-Language Display | English, French, Spanish Portuguese, Chinese (Simplified) |
| Steering Wheel Control Ready (Adapter Sold Separately) | Yes |
KNOWLEDGEBASE
| Apple CarPlay with iOS 13 on Pioneer NEX receivers |
MVH-1400NEX - What's in the Box? |
