DMH-2660NEX
DMH-2660NEX
- 6.8" - Amazon Alexa, Android Auto™, Apple CarPlay™, Bluetooth®, HD Radio™, SiriusXM-Ready™ - Multimedia Digital Media Receiver
- 6.8" WVGA (Capacitive Touch)
- Apple CarPlay™ Compatible
- Android Auto™ Compatible
- Amazon Alexa Built-in when Paired with Pioneer Vozsis App
- HD Radio™
- SiriusXM-Ready™
- Built-in Bluetooth®
- iDataLink® Maestro™ Compatible
- Notice: Connection to Spotify app on Android
What’s in the Box
- Digital media receiver
- Wiring harness
- Remote control
- CR2025 3V lithium battery
- 58" USB extension cable
- Microphone
- A package of screws and 2 sided tape
- Installation Manual
- Quick Start Guide
- Warranty Sheet
Specification
STANDARDS
| CTA-2006 | Yes |
PERFORMANCE
| Continuous Power Output | 22 W x 4-Channel |
| Load Impedance Allowance | 4 Ohm (4 Ohm to 8 Ohm Allowable) |
| Max Power Output | 50 W x 4-ch 4 ohm / 50 W x 2-ch 4 ohm 70 W X 1-ch (subwoofer) 2 Ohm |
| RCA Preamp Outputs | 6-ch |
| RCA Pre-out | 4V |
| RMS Power Output (CTA-2006) | 14 W RMS x 4-ch 4 ohm |
DISPLAY
| Back Light | LED |
| Brightness Control | Yes |
| Color Customization | 5 display colors, 112 key colors |
| Device (Non-DIN/Modular Unit) | 2-DIN |
| Dimmer | Automatic with vehicle illumination, Timer Controlled, Manual |
| Display Off Mode | Yes |
| Home Screen Customization | Yes |
| Monitor Mechanism | Fixed |
| Resolution | WVGA (800 x 480) |
| Screen Size/Aspect Ratio | 6.8"/16:9 |
| Touch Screen | Capacitive |
BLUETOOTH
| Advanced Audio Distribution Profile (A2DP) | Yes |
| AVRCP | 1.4 |
| Built-in Bluetooth® | Yes |
| Dual Phone Connection | Yes |
| Hands Free Version | 1.6 |
| Hands-Free | Yes |
| Microphone Included | Included |
| Phone Registration | 5-phone |
| Secure Simple Pairing (SSP) | Yes |
| Serial Port Profile (SPP) | Yes |
| Sound Retriever Air | Mode 1/Mode 2/Off |
TUNER
| Best Station Memory | Yes |
| HD Radio™ | Built In / Artist Experience / Multicasting |
| Local Seek tuning | Yes |
| Presets | 18 FM, 6 AM |
| RDS | Yes |
| SiriusXM-Ready™ (Tuner Sold Separately) | Yes |
| Supertuner® IIID | Yes |
INTEGRATION
| Amazon Alexa | Paired with Pioneer Vozsis |
| Android Auto™ | Wired USB Connection |
| Apple® CarPlay | Wired USB Connection |
| Mobile Operating System | Android / Apple iOS |
| Music Playback (MTP) | Yes |
| Pandora® | With Apple CarPlay or Android Auto |
| Pioneer App Compatibility | Vozsis Android, Vozsis iPhone |
| Siri® Eyes Free (VR) (Internet Required) | iPhone Only |
| Spotify | Streaming audio through iPhone/Android via Bluetooth or AUX input |
| Voice Control | Yes |
| Weblink | Yes |
DIGITAL MEDIA PLAYBACK
| Audio Playback via USB | MP3 Audio Playback / WMA Audio Playback / WAV Audio Playback (Hi-Res) / AAC Audio Playback / FLAC Audio Playback (Hi-Res) |
| Audio Video Playback via USB | .avi / .mpg/mpeg / .divx / .mp4 / .3gp / .mkv / .mov / .flv / .wmv/.asf / .m4v / .ts/.m2ts/.mts / H.263 / H.264 |
| Image Display via USB | BMP / JPEG / PNG |
AUDIO
| Advanced Sound Retriever | Mode-1/Mode-2/Off |
| Bass Boost | Yes |
| Auto EQ (CD-MC20 Microphone sold separately) | Yes |
| Automatic Level Control | Mode-1/Mode-2/Off |
| Balance | Yes |
| Built-in Amplifier | MOSFET 50 W x 4 |
| Crossover Network Mode | HPF/Band Pass/LPF |
| Crossover Standard Mode | HPF/LPF |
| Customizable Graphic Equalizer | 13 Band |
| DA Converter | 24 Bit |
| Digital Signal Processor | Built In |
| Easy EQ (EEQ) Preset Equalizer | Yes |
| Fade | Yes |
| Listening Position Selector | Yes |
| Loudness | High/Mid/Low/Off |
| Speaker Output | 4-ch |
| Spectrum Analyzer | Yes |
| Subwoofer Control | Yes |
| Time Alignment | Auto / Manual |
EXPANDABILITY
| OEM Integration | iDatalink® Maestro™ - RR (DATA) |
| Parking Assist Lines | Yes |
| RCA Video Output | Yes |
| USB | Single Rear Type-A (5 V, 1.5 A) |
| USB Direct Control for iPhone® | 5s and newer |
INPUTS
| Input 1 | Backup Camera Dedicated |
| Input 2 | AUX (Minijack) |
| Input 3 | AV |
GENERAL
| Detachable Face Security | Fixed |
| Multi-Language Display | English, French, Spanish Portuguese, Chinese (Simplified) |
| Music Browser | USB |
| Remote Control | Included |
| Steering Wheel Control Ready (Adapter Sold Separately) | Yes |
